Standard Rubber Repair Strip (Repair Patch) is made of synthetic rubber compound with a superior quality semi-vulcanized bonding layer on one side. It is a highly wear-resistant, and natural rubber strip designed for use to repair damage to the conveyor belt. As the authentic CN layer(bonding layer), the Adhesive Force reached about 9N/mm after bond 72 hours. and the CN layer’s featured characteristic is that its adhesive force increases with time, while the adhesion of the inferior CN layer adhesion doesn’t change over time.
Conveyor Belt Repair Strip
Description
Rubber Repair Strips are specially designed materials for efficient belt restoration, enabling quick damage repair and operational recovery.
| Item | Description | Size ( Thick*W*L) mm |
| 1 | Standard Rubber Repair Strip | 2.2*100*10000 |
| 2 | Standard Rubber Repair Strip | 3.2*150*10000 |
| 3 | Standard Rubber Repair Strip | 3.2*220*10000 |
| 4 | Standard Rubber Repair Strip | 3.4*300*10000 |
| 5 | Standard Rubber Repair Strip | 3.4*400*10000 |
| 6 | Fabric Reinforced Repair Strip | 3.6*100*10000 |
| 7 | Fabric Reinforced Repair Strip | 4.6*150*10000 |
| 8 | Fabric Reinforced Repair Strip | 4.6*220*10000 |
| 9 | Fabric Reinforced Repair Strip | 4.8*300*10000 |
| 10 | Fabric Reinforced Repair Strip | 4.8*400*1000 |
More customized sizes are available.
For an optimized cold repair result of belt damage, we recommend using TRS/REMA/Nilos adhesive and Hardener.
Feature
1. It doesn’t need to remove the conveyor belt from the conveyor system. It is quick in repair and easy to operate, thus maintaining your conveyor belt system in good operational condition.
2. The conveyor belt can be used once the repair operation is finished.
3. The repair may last as long as the original belt remains in service
4. Label & Package and Sizes can be Customized
5. All Rubber repair strips feature a bonding layer that offers superior adhesion when they bond to the rubber conveyor belt surface; the bonding layer doesn’t need to be polished before use and can be bonded directly always.
7. Beltcare Solution Rubber Repair Strips (Patch) are produced complying with global standards including DIN, AS (Australia), EN-ISO (Europe), etc.
